Straight Truss Gangway

Brand: Safe Harbor Access Systems
Request Information
Truss gangways are used to facilitate loading and unloading of cargo from ships and offshore platforms. They must accommodate the size and load of the cargo while providing safe secure footing for personnel and the equipment used to move the cargo.

In addition, the gangways need to provide safe passage in both high and low tides and when the ships are full and riding low in the water, or empty of cargo and riding high.

Safe Harbor’s engineers have the experience and application knowledge to design an aluminum truss gangway that will meet your cargo requirements and safely adjust to the varying levels of the water and the ship throughout loading and unloading. We specialize in custom designs and have the capabilities to design and manufacture your truss gangway to meet your deadline and budget.
Features
  • Custom truss depth to provide maximum support and safety based on the length, capacity, and use of the gangway.  The standard depth is 60 lbs./sq. ft.
  • Decking in aluminum sheet, treadplate, open grating, or extruded decking to provide easy transport of cargo with maximum safety
  • Flat ramp
  • Variety of cleat styles to allow for more secure footing at steeper angles and increase the load distribution of your cargo
  • Self-leveling mountings
  • Construction using aluminum alloys specifically designed for use in marine and saltwater environments with welded joints that are corrosion- and saltwater-resistant
Truss gangways are used to facilitate loading and unloading of cargo from ships and offshore platforms. They must accommodate the size and load of the cargo while providing safe secure footing for personnel and the equipment used to move the cargo.

In addition, the gangways need to provide safe passage in both high and low tides and when the ships are full and riding low in the water, or empty of cargo and riding high.

Safe Harbor’s engineers have the experience and application knowledge to design an aluminum truss gangway that will meet your cargo requirements and safely adjust to the varying levels of the water and the ship throughout loading and unloading. We specialize in custom designs and have the capabilities to design and manufacture your truss gangway to meet your deadline and budget.
Features
  • Custom truss depth to provide maximum support and safety based on the length, capacity, and use of the gangway.  The standard depth is 60 lbs./sq. ft.
  • Decking in aluminum sheet, treadplate, open grating, or extruded decking to provide easy transport of cargo with maximum safety
  • Flat ramp
  • Variety of cleat styles to allow for more secure footing at steeper angles and increase the load distribution of your cargo
  • Self-leveling mountings
  • Construction using aluminum alloys specifically designed for use in marine and saltwater environments with welded joints that are corrosion- and saltwater-resistant
Close

Specifications

Brand

Width

  • 24” Standard
  • 36”

Track Length

  • 10 to 22 ft in Two Feet Increments

Typical Pivot Range

  • ± 15°
  • ± 30°

Gangway Operation

  • Manual (Up to 12 Steps)
  • Pneumatic (Up to 24 Steps)
  • Hydraulic (Up to 34 Steps)

Pneumatic Operation

  • Available Pressure: 80 psi

Hydraulic Operation

  • 120/1/60 Vac; 230/460/3/60 Vac; Non-Classified - NEMA 4/3R; Classified - NEMA 7&9/CL 1, DIV 2, GRP C&D

Tracking Drive

  • Manual (Small Units)
  • Powered

Live Load Capacity

  • 500#
  • 750#
  • 1,000#

Gangway Hardware

  • Plated Steel
  • Stainless Steel

Standard

  • OSHA and OSHA Voluntary Protection Program (VPP) Standards
Close

Applications

  • On Oil & Gas Offshore Platforms & Refineries
  • Naval Vessels
  • Transport Ships
  • Barges
  • Cargo Vessels
  • Container Ships
Close
