Approvals & Certifications
- EN 14015, 12874
- ISO 28300 (API 2000), ISO 6358, ISO 16016
- TÜV (Technischer Uberwachungsverein)
Approvals & Certifications
- ATEX
- CEN
- IEC
- NEC Group D MESG > 0.90 mm
Environmental Protection
- Explosion-proof Groups IIA
Flange Size - 2” (DN 50)
- 2” (DN 50) - 150# ASME B16.5
Flange Size - 3” (DN 80)
- 3” (DN 80) - 150# ASME B16.5
Flange Type
- Raised Face (RF)
- Smooth Finish
Materials of Construction
- Heating Jacket, Flamefilter Cage, Spacer, Weather Hood, Valve Pallet: Stainless Steel
- Heating Jacket, Weather Hood: Steel
- Valve Pallet: Aluminum
Operating Temperature
- 0° to 60° C (32° to 140° F)
Pressure Range
- psi: 0.050 to 3.046 (kPa: 0.35 to 21, Mbar: 3.5 to 210)
Seat / Seal Material
- Seal: FEP
- Seal: Metal
- Seal: PTFE
- Valve Seat: Stainless Steel
